| Colors |
|
|
Engine |
|
| |
Jet Black & Lightning Yellow |
|
Type |
Liquid-cooled, DOHC in-line 4 cylinder |
| |
Tornado Red & Aluminium Silver |
|
Capacity |
599cc |
| |
|
|
Bore/Stroke |
68 x 41.3mm |
| Cycle
Parts |
|
|
Compression Ratio |
12:1 |
| Frame |
Aluminium beam perimeter |
|
Fuel System |
Multipoint sequential electronic fuel injection
with forced air induction |
| Swingarm |
Twin sided, aluminium alloy |
|
Ignition |
Digital - inductive type - via electronic
management system |
| Front Wheel |
Alloy 3 spoke, 17 x 3.5in |
|
Performance |
|
| Rear Wheel |
Alloy 3 spoke, 17 x 5.5in |
|
Maximum Power |
108bhp at 12,750rpm |
| Front Tire |
120/70 ZR 17 |
|
Maximum Torque |
50.5 ft-lb at 11,000rpm |
| Rear Tire |
180/55 ZR 17 |
|
Dimensions |
|
| Front Suspension |
42mm cartridge forks with dual rate springs and
adjustable preload, compression and rebound damping |
|
Length |
81.1in |
| Rear Suspension |
Monoshock with adjustable preload, rebound and
remote compression |
|
Width |
26.2in |
| Front Brakes |
Twin 310mm floating discs, four-piston calipers |
|
Height |
45.3in |
| Rear Brakes |
Single 220mm disc, single piston caliper |
|
Seat Height |
31.9 |
| Transmission |
|
|
Wheelbase |
54.9 |
| Primary Drive |
Gear |
|
Rake/Trail |
24o/82mm |
| Final Drive |
525 X ring chain |
|
Weight (Dry) |
374lbs |
| Clutch |
Wet, multi plate |
|
Fuel Capacity |
4.8 gal |
| Gearbox |
6 speed |
|
|
|
