| Colors |
|
|
Engine |
|
| |
Opal White & Tangerine |
|
Type |
Liquid-cooled, DOHC, in-line 3-cylinder |
| |
|
|
Capacity |
885cc |
| |
|
|
Bore/Stroke |
76 x 65mm |
| Cycle
Parts |
|
|
Compression Ratio |
10:1 |
| Frame |
Micro alloyed high tensile steel spine |
|
Fuel System |
3 x 36mm flat slide CV carburetors |
| Swingarm |
Twin sided, aluminium alloy |
|
Ignition |
Digital - inductive type |
| Front Wheel |
36 spoke, 17 x 3.5in |
|
Performance |
|
| Rear Wheel |
40 spoke, 17 x 4.25in |
|
Maximum Power |
82bhp at 8,500rpm |
| Front Tire |
120/70 R 17 |
|
Maximum Torque |
56ft-lb at 6,500rpm |
| Rear Tire |
160/70 R 17 |
|
Dimensions |
|
| Front Suspension |
43mm cartridge forks with triple rate springs
with adjustable preload, compression and rebound damping |
|
Length |
88.6in |
| Rear Suspension |
Monoshock with adjustable preload, compression
and rebound damping |
|
Width |
33.8in |
| Front Brakes |
Twin 310mm discs, 2 piston calipers |
|
Height |
43.5in |
| Rear Brakes |
Single 285mm disc, 2 piston caliper |
|
Seat Height |
31.1in |
| Transmission |
|
|
Wheelbase |
62.2in |
| Primary Drive |
Gear |
|
Rake/Trail |
27o/106mm |
| Final Drive |
O ring chain |
|
Weight (Dry) |
494lb |
| Clutch |
Wet, milti-plate |
|
Fuel Capacity |
4 gal. |
| Gearbox |
6-speed |
|
|
|
